TPS709
PRODUCTION DATA
1
Features
2
Applications
3
Description
4
Revision History
5
Pin Configuration and Functions
6
Specifications
6.1
Absolute Maximum Ratings
6.2
ESD Ratings
6.3
Recommended Operating Conditions
6.4
Thermal Information
6.5
Electrical Characteristics
6.6
Typical Characteristics
7
Detailed Description
7.1
Overview
7.2
Functional Block Diagram
7.3
Feature Description
7.3.1
Internal Current Limit
7.3.2
Dropout Voltage
7.3.3
Undervoltage Lockout (UVLO)
7.3.4
Reverse-Current Protection
7.4
Device Functional Modes
8
Application and Implementation
8.1
Application Information
8.1.1
Input and Output Capacitor
8.1.2
Transient Response
8.2
Typical Application
8.2.1
Design Requirements
8.2.2
Detailed Design Procedure
8.2.3
Application Curves
9
Power Supply Recommendations
9.1
Power Dissipation
10
Layout
10.1
Layout Guidelines
10.1.1
Thermal Protection
10.2
Layout Example
11
Device and Documentation Support
11.1
Device Support
11.1.1
Development Support
11.1.1.1
Evaluation Modules
11.1.1.2
Spice Models
11.1.2
Device Nomenclature
11.2
Documentation Support
11.2.1
Related Documentation
11.3
Support Resources
11.4
Trademarks
11.5
Electrostatic Discharge Caution
11.6
Glossary
12
Mechanical, Packaging, and Orderable Information
Package Options
Mechanical Data (Package|Pins)
DRV|6
MPDS216E
DBV|5
MPDS018T
Thermal pad, mechanical data (Package|Pins)
DRV|6
QFND087M
Orderable Information
sbvs186h_oa
sbvs186h_pm
1
Features
Ultra-low I
Q
: 1 μA
Reverse current protection
Low I
SHUTDOWN
: 150 nA
Input voltage range: 2.7 V to 30 V
Supports 200-mA peak output
2% accuracy over temperature
Available in fixed-output voltages:
1.2 V to 6.5 V
Thermal shutdown and overcurrent protection
Packages: SOT-23-5, WSON-6
