SBOA436
October 2020
OPA192
Design Goals
Design Description
Design Notes
Design Steps
Design Simulations
DC Simulation Results
Design References
Design Featured Op Amp
Design Alternate Op Amp
Design Goals
Input V
in
(V
p
– V
n
)
Output
Supply
V
inMin
V
inMax
I
Min
I
Min
VS+
VS-
V
ref
–5V
5V
–25mA
25mA
15V
–15V
0V
