C2000™ F280013x Series LaunchPad™ Development Kit
1 C2000 F280013x Series LaunchPad Development Kit
The LAUNCHXL-F2800137 is a low-cost development board for the Texas Instruments C2000™ Real-Time Microcontroller series of F280013x devices. The LAUNCHXL-F2800137 is designed around the TMS320F2800137 real-time MCU and highlights the control, analog, and communications peripherals, as well as the integrated nonvolatile memory. The LaunchPad™ Development Kit also features two independent BoosterPack™ XL expansion connectors (80-pins), on-board Controller Area Network (CAN) transceiver, one 5-V encoder interface (eQEP) connector, power-domain isolation, and an on-board XDS110 debug probe.
Figure 1-1 highlights the key features of the F280013x LaunchPad.
Figure 1-1 F280013x LaunchPad™ Board OverviewTrademarks
C2000™, LaunchPad™, BoosterPack™, and Code Composer Studio™ are trademarks of Texas Instruments.
All trademarks are the property of their respective owners.
1 Board Overview
1.1 Kit Contents
The F280013x Series LaunchPad Development Kit contains these items:
- C2000 F280013x Series LaunchPad development board (LAUNCHXL-F2800137)
- USB Type-A male to USB Type-C™ male cable
- Pinout Map
1.2 Features
The F280013x LaunchPad has these features:
- C2000 Series F2800137PM (64-pin) Real-time Microcontroller
- On-board XDS110 debug probe
- Two user-controlled LEDs
- One microcontroller reset switch
- Selectable power domains:
- USB (isolated)
- BoosterPack
- External power supply
- CAN connector with on-board CAN transceiver
One independent Enhanced Quadrature Encoder Pulse (QEP)-based encoder connectors
- Two independent BoosterPack XL standard connectors (80-pins) featuring stackable headers to maximize expansion through the BoosterPack ecosystem
1.3 Specifications
Table 1-1 summarizes the F280013x LaunchPad specifications.
| Parameter | Value |
|---|---|
| Board Supply Voltage |
5 VDC from one of the following sources:
|
| Dimensions | 5.5 in x 2.3 in x .425 in (13.97 cm x 5.84 cm x 10.8 mm) (L x W x H) |
| Break-out Power Output | 3.3 VDC to BoosterPacks, limited by output of TPS7A3701 LDO. This 3.3-V plane is shared with on-board components. Total output power limit of TPS7A3701 is 1 Amp. |
| Assumed Operating Conditions | This kit is assumed to run at standard room conditions. The EVM can run at approximately standard ambient temperature and pressure (SATP) with moderate-to-low humidity. |
